ESD Protection Diode ESD8V0D5B
Single Channel 8V Bidirectional ESD Diode in SOD523 Package
Description
Features
Package
| Parameter | Symbol | Value | Unit |
| Maximum Reverse Peak Pulse Current(8/20μS) | Ipp | 8 | A |
| ESD per IEC 61000−4−2 (Air) | VESD | ±30 | KV |
| ESD per IEC 61000−4−2 (Contact) | VESD | ±30 | KV |
| Storage Temperature Range | TSTJ | -55 to +150 | ℃ |
| Operating Temperature Range | TJ | -40 to +125 | ℃ |
| Lead Soldering Temperature | TL | 260 (10 sec) | ℃ |
| P/N | Bi/Uni | Channel | VRWM | VBR | Reverse Current @VRWM | Clamping Voltage | Diode Capacitance VR = 0V, f = 1MHz | IPP | ESD per IEC 61000−4−2 | Status | Samples | ||||
| Max(V) | Min(V) | Max(V) | Min(μA) | Max(V) | Max(pF) | A | VESD(Air) | VESD(Contact) | |||||||
| ESD8V0D5B | Bi | 1 | 8 | 8.2 | 11 | 0.5 | 12 | 30 | 8 | 30 | 30 |  | Request sample | ||
Related Application
Touch Screen
RS-485
USB
SD
Key
MIC
Type-C
CAN
