ESD Protection Diode ESDA0504T5
5V Bidirectional ESD Diode in SOT-553 Package
Description
Features
Package
| Parameter | Symbol | Value | Unit |
| Peak pulse power (tp = 8/20μs) | PPP | 60 | W |
| ESD per IEC 61000−4−2 (Air) | VESD | ±15 | KV |
| ESD per IEC 61000−4−2 (Contact) | VESD | ±8 | KV |
| Storage Temperature Range | TSTJ | -55 to +150 | ℃ |
| Operating Temperature Range | TJ | -55 to +125 | ℃ |
| P/N | Bi/Uni | VRWM | VBR | Reverse Current @VRWM | Clamping Voltage | Diode Capacitance VR = 0V, f = 1MHz | IPP | ESD per IEC 61000−4−2 | Status | Samples | ||||
| Max(V) | Min(V) | Max(V) | Min(μA) | Max(V) | Max(pF) | A | VESD(Air) | VESD(Contact) | ||||||
| ESDA0504T5 | Bi | 5 | 6 | - | 0.5 | - | 12 | - | 15 | 8 |  | Request sample | ||
Related Application
LIN
RS-485
SD
eSATA
SIM
CVBS
Touch Screen
GPS
