ESD Protection Diode NRESDLC24VAPBETH
AEC-Q101 qualified 24V ESD Diode in SOT23 Package
Description
Features
Package
| Parameter | Symbol | Value | Unit |
| Maximum Reverse Peak Pulse Current(8/20μS) | IPP *1 | 2 | A |
| ESD per IEC 61000−4−2 (Air) | VESD | ±30 | KV |
| ESD per IEC 61000−4−2 (Contact) | VESD | ±30 | KV |
| Storage Temperature Range | TSTJ | -55 to +150 | ℃ |
| Operating Temperature Range | TJ | -55 to +150 | ℃ |
| P/N | VRWM | VBR | Reverse Current @VRWM | Clamping Voltage | Diode Capacitance VR = 0V, f = 1MHz | IPP | ESD per IEC 61000−4−2 | Status | Samples | ||||
| Max(V) | Min(V) | Max(V) | Min(μA) | Max(V) | Max(pF) | A | VESD(Air) | VESD(Contact) | |||||
| NRESDLC24VAPBETH | 24 | - | - | 0.1 | - | 2 | 2.0 | 30 | 30 |  | Request sample | ||
Related Application
DC 48V
USB
RJ45
Ethernet
POE
HDMI
CAN
G.Fast
