| Image | Product Name | Package | Protection features | Data sheet | Inquiry | Add to basket |
|---|---|---|---|---|---|---|
 | 15KP Series 15000W Axial Leaded TVS Diode | P-600 | 1kW-15kW | 15KP Series.pdf | Inquire | Add to Basket |
 | 5KP Series 5000W TVS Diode | P-600 | 1kW-15kW | 5KP Series.pdf | Inquire | Add to Basket |
 | 3KP Series 3000W TVS Diode | P-600 | 1kW-15kW | 3KP Series.pdf | Inquire | Add to Basket |
 | 1.5KE Series 1500W Transient Voltage Suppressors | D0-201 | 1kW-15kW | 1.5KE Series.pdf | Inquire | Add to Basket |
 | P6KE Series 600W Axial Leaded TVS Diode | D0-15 | 200W-600W | P6KE Series.pdf | Inquire | Add to Basket |
 | SA Series 500W Transient Voltage Suppressors | D0-15 | 200W-600W | SA SERIES.pdf | Inquire | Add to Basket |
 | 5.0SMDJ Series 5000W TVS Diode(DO-214AB) | DO-214AB | 1kW-15kW | 5.0SMDJ Series.pdf | Inquire | Add to Basket |
 | SMDJ Series 3000W TVS Diode | DO-214AB | 1kW-15kW | SMDJ Series.pdf | Inquire | Add to Basket |
 | SMCJ 1500W TVS diode | DO-214AB | 1kW-15kW | SMCJ Series.pdf | Inquire | Add to Basket |
 | 1.0SMB Series 1000W TVS Diode | DO-214AA | 600W-1000W | 1.0SMB Series.pdf | Inquire | Add to Basket |
 |
| Quantity: | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| The Schottky diode (named after the German physicist Walter H. Schottky), also known as Schottky barrier diode or hot-carrier diode, is a semiconductor diode formed by the junction of a semiconductor with a metal. It has a low forward voltage drop and a very fast switching action. The cat's-whisker detectors used in the early days of wireless and metal rectifiers used in early power applications can be considered primitive Schottky diodes. | |||||||||
We are a professional enterprise engaged in the manufacture and sale of Schottky Barrier Diodes.
Manufacture Process:
Advantages:
Faster recovery time. The small amount of charge stored within a Schottky diode makes it ideal for high speed switching applications.
Less noise. The Schottky diode will produce less unwanted noise than your typical p-n junction diode.
Better performance.
Ability to regulate and stabilize circuit voltage.
Greater control overflowing current.
Usable in smaller circuits.
Application:
Schottky diodes are used in electronics industry for many applications in diode rectifier because of its properties. They are used for voltage clamping applications, to prevent transistor saturation. It is used as Schottky TTL in digital devices as these devices require fast switching. as the performance of digital computers is determined by switching speed of diodes, Schottky diode is an important component for digital computers.
YINT Brand Introduction:
YINT Electronics, established in 2006, a leading provider of circuit protector and solution service, integrates R&D, production, sales and service in one, it has its own intellectual property rights in all the products, the products are mainly sold to more than 20 domestic cities and more than 10 countries worldwide. Our headquarter is in Shanghai and our factory is located in Wuhu, now we have 200 employees and 50 employees among them are in charge of management, design and techniques.
Production Capacity and Equipment:
YINT has been accredited with ISO9001 quality system certification in 2007 and now we have 19 Certificates of Utility Model Patent. Our company has imported high-tech production and testing equipment, all the products comply with RoHS requirements; many series of products are certified by international safety regulatory agencies, such as UL, VDE, CSA, etc.
Exhibition:
2019 Korea Electronics Show (KES)
Electronica China 2019
Electronica China 2020
Questions you may be concerned about
1. Can you provide samples of schottky barrier diodes? is it free or extra?
Free samples for testing.
Professional electronic solutions according to customers' demands.
Customized schottky barrier diodes products.
2. Can you provide competitive prices for schottky barrier diodes?
1) The price is different according to customers' needs and quantity requirements.
2) The customized products will incur additional production costs.
3. What is your payment term?
100% TT in advance in first stage.
4. Schottky Barrier Diodes Packing and Delivery Issues:
1) The schottky barrier diodes will be packed in reel or plastic case type, as photos.
2) Envelope for small quantity, carton for large quantity, extra wraping materials will be applied to long-distance transportation.
3) Lead time: usually within 10 working days after payement.
4) Port: Shanghai
5) Shipping Methods: DHL, Fedex, by sea, etc(Negotiable)
5. How is your quality control carried out?/ How do you ensure schottky barrier diodes quality?
1) We have a professional QC Department, every part must be passed by QC from our company before shippment.
2) If there are any quality problems after you receving the products, please make sure that all items are in their original conditions for refund or replacement.
3) Our technical engineer team provides professional solutions and other technical consulting services.
4) Our professional foreign trade team follows up all the delivery process of each order.
Knowledge
1. What is a Schottky Barrier Diode?
A Schottky barrier diode (SBD) is a device in which a semiconductor and a metal such as molybdenum are bonded instead of a pn junction. In general, semiconductors in which metals are bonded to n-type layers have been commercialized. It is suitable for high-speed switching applications, because of small forward voltage and short reverse recovery time.
2. How does a Schottky Barrier Diode work?
In a Schottky diode, a semiconductor–metal junction is formed between a semiconductor and a metal, thus creating a Schottky barrier. The N-type semiconductor acts as the cathode and the metal side acts as the anode of the diode. This Schottky barrier results in both a low forward voltage drop and very fast switching.
3. Where to use Schottky Barrier Diode?
Schottky diodes are used for the voltage clamping applications and prevention of transistor saturation due to the high current density in the Schottky diode. It’s also been a low forward voltage drop in Schottky diode, it is wasted in less heat, making them an efficient choice for applications that are sensitive and very efficient. Because of the Schottky diode used in stand-alone photovoltaic systems in order to prevent batteries from discharging purpose for the solar panels at night as well as in grid-connected systems, containing multiple strings are connected in parallel connection. Schottky diodes are also used as rectifiers in power supplies.
4. What are the advantage of Schottky Barrier Diode?
One of the primary advantages of using a Schottky diode over a regular diode is their low forward voltage drop. This allows a Schottky diode to consume less voltage than a standard diode, using only 0.3-0.4V across its junctions.
5. How to test a Schottky Diode?
Connect the red positive test lead to the anode of the Schottky diode and the black common test lead to the cathode of the diode. Listen for a “beep” or a “buzz” from the multimeter. If the Schottky diode responds as expected, the multimeter will sound a tone.
If you are interested in any of our schottky barrier diodes. or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
Hot Tags: schottky barrier diodes, China, manufacturers, factory, price, SMC Schottky Rectifiers, Schottky Barrier Diodes, TO 277 Schottky Diode, SMA schottky diode, Surface Mount Schottky Barrier Rectifier, Schottky Diode
