Add to Compare Image Product Name Data sheet Package Protection features Clamping voltage (V) Number of channels
15KP Series 15000W Axial Leaded TVS Diode 15KP Series 15000W Axial Leaded TVS Diode 15KP Series.pdf P-600 1kW-15kW 29.3-454.5V 1
5KP Series 5000W TVS Diode 5KP Series 5000W TVS Diode 5KP Series.pdf P-600 1kW-15kW 9.2-425V 1
3KP Series 3000W TVS Diode 3KP Series 3000W TVS Diode 3KP Series.pdf P-600 1kW-15kW 9.2-371.1V 1
1.5KE Series 1500W Transient Voltage Suppressors 1.5KE Series 1500W Transient Voltage Suppressors 1.5KE Series.pdf D0-201 1kW-15kW 10.5-760V 1
P6KE Series 600W Axial Leaded TVS Diode P6KE Series 600W Axial Leaded TVS Diode P6KE Series.pdf D0-15 200W-600W 10.5-828V 1
SA Series 500W Transient Voltage Suppressors SA Series 500W Transient Voltage Suppressors SA SERIES.pdf D0-15 200W-600W 9.2-308V 1
5.0SMDJ Series 5000W TVS Diode(DO-214AB) 5.0SMDJ Series 5000W TVS Diode(DO-214AB) 5.0SMDJ Series.pdf DO-214AB 1kW-15kW 18.2-275V 1
SMDJ Series 3000W TVS Diode SMDJ Series 3000W TVS Diode SMDJ Series.pdf DO-214AB 1kW-15kW 9.2-356V 1
SMCJ 1500W TVS diode SMCJ 1500W TVS diode SMCJ Series.pdf DO-214AB 1kW-15kW 9.2-713V 1
1.0SMB Series 1000W TVS Diode 1.0SMB Series 1000W TVS Diode 1.0SMB Series.pdf DO-214AA 600W-1000W 10.5-64.8V 1
P8SMB Series 800W TVS Diode P8SMB Series 800W TVS Diode P8SMB Series.pdf DO-214AA 600W-1000W 10.5-567V 1
P6SMB Series 600W SMD TVS Diode P6SMB Series 600W SMD TVS Diode P6SMB Series.pdf DO-214AA 200W-600W 10.5-567V 1
SMAJ 400W TVS diode SMAJ 400W TVS diode SMAJ Series.pdf DO-214AC 200W-600W 9.2-290V 1
SMBJ 600W TVS diode SMBJ 600W TVS diode SMBJ Series.pdf DO-214AA 200W-600W 9.2-713V 1
SMDJ-H Series Surface Mount TVS Diode SMDJ-H Series Surface Mount TVS Diode SMDJ-H Series.pdf
SMCJ-H Series TVS Diode SMD SMCJ-H Series TVS Diode SMD SMCJ-HSeries.pdf
SMBJ-H Series Transient Voltage Suppressors SMBJ-H Series Transient Voltage Suppressors SMBJ-H Series.pdf
SMAJ-H Series Transient Voltage Suppressor Diode SMAJ-H Series Transient Voltage Suppressor Diode SMAJ-H Series.pdf
5.0 SMDJ-H Series Surface Mount Transient Voltage Suppressor 5.0 SMDJ-H Series Surface Mount Transient Voltage Suppressor 5.0SMDJ-H Series.pdf
SM8 6600W TVS diode SM8 6600W TVS diode SM8S.pdf D0-218AB 1kW-15kW 29.2-69.4V 1
Package: P-600
Protection features: 1kW-15kW
Clamping voltage (V): 29.3-454.5V
Number of channels: 1
Package: P-600
Protection features: 1kW-15kW
Clamping voltage (V): 9.2-425V
Number of channels: 1
Package: P-600
Protection features: 1kW-15kW
Clamping voltage (V): 9.2-371.1V
Number of channels: 1
Package: D0-201
Protection features: 1kW-15kW
Clamping voltage (V): 10.5-760V
Number of channels: 1
Package: D0-15
Protection features: 200W-600W
Clamping voltage (V): 10.5-828V
Number of channels: 1
Package: D0-15
Protection features: 200W-600W
Clamping voltage (V): 9.2-308V
Number of channels: 1
Package: DO-214AB
Protection features: 1kW-15kW
Clamping voltage (V): 18.2-275V
Number of channels: 1
Package: DO-214AB
Protection features: 1kW-15kW
Clamping voltage (V): 9.2-356V
Number of channels: 1
Package: DO-214AB
Protection features: 1kW-15kW
Clamping voltage (V): 9.2-713V
Number of channels: 1
Package: DO-214AA
Protection features: 600W-1000W
Clamping voltage (V): 10.5-64.8V
Number of channels: 1
Package: DO-214AA
Protection features: 600W-1000W
Clamping voltage (V): 10.5-567V
Number of channels: 1
Package: DO-214AA
Protection features: 200W-600W
Clamping voltage (V): 10.5-567V
Number of channels: 1
Package: DO-214AC
Protection features: 200W-600W
Clamping voltage (V): 9.2-290V
Number of channels: 1
Package: DO-214AA
Protection features: 200W-600W
Clamping voltage (V): 9.2-713V
Number of channels: 1
Package:
Protection features:
Clamping voltage (V):
Number of channels:
Package:
Protection features:
Clamping voltage (V):
Number of channels:
Package:
Protection features:
Clamping voltage (V):
Number of channels:
Package:
Protection features:
Clamping voltage (V):
Number of channels:
Package:
Protection features:
Clamping voltage (V):
Number of channels:
Package: D0-218AB
Protection features: 1kW-15kW
Clamping voltage (V): 29.2-69.4V
Number of channels: 1
Quick Search
Package
Protection features
Number of channels
Clamping voltage (V)
Products
SELECTED PRODUCT LINES:
15KP Series 15000W Axial Leaded TVS Diode
Package name: P600
P600 glass passivated chip junction
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min.
High Temperature soldering: 260°C/10 seconds at terminals.
Solder dip 275 °C max. 10 s, per JESD 22-B106
5KP Series 5000W TVS Diode
Package name: P600
P600 glass passivated chip junction
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min.
High Temperature soldering: 260°C/10 seconds at terminals.
Solder dip 275 °C max. 10 s, per JESD 22-B106
3KP Series 3000W TVS Diode
Package name: P600
P600 glass passivated chip junction
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min.
High Temperature soldering: 260°C/10 seconds at terminals.
Solder dip 275 °C max. 10 s, per JESD 22-B106
1.5KE Series 1500W Transient Voltage Suppressors
Package name: DO-201
P600 glass passivated chip junction
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min.
High Temperature soldering: 260°C/10 seconds at terminals.
Solder dip 275 °C max. 10 s, per JESD 22-B106
P6KE Series 600W Axial Leaded TVS Diode
Package name: DO-15
DO-15 glass passivated chip junction
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min
High Temperature soldering: 260°C/10 seconds at terminals.
Solder dip 275 °C max. 10 s, per JESD 22-B106
SA Series 500W Transient Voltage Suppressors
Package name: DO-15
Plastic package
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current
Fast response time: typically less than 1.0ps from 0 Volts to BV min.
High Temperature soldering: 260°C/10 seconds at terminals
Solder dip 275 °C max. 10 s, per JESD 22-B106
5.0SMDJ Series 5000W TVS Diode(DO-214AB)
5000W peak pulse power capability at 10/1000μs waveform, repetition rate (duty cycles):0.01%
SMD low profile surface mount package minimizing PCB footprin
Typical failure mode is short from over-specified voltage or current
Whisker test is conducted based on JEDEC JESD201A per its table 4a and 4c
Fast response time: typically less than 1.0ps from 0V to BV min
Excellent clamping capability
Low incremental surge resistance
SMDJ Series 3000W TVS Diode
Package name: DO-214AB/SMC
For surface mounted applications in order to optimize board space.
Polarity: Color band denoted positive end (cathode) except Bidirectional.
Typical failure mode is short from over-specified voltage or current.
High Temperature soldering:260°C/10 seconds at terminals.
Terminal: Solder plated, solderable per MIL-STD-750,Method 2026.
